DEFI ADVANCE CONTROL UNIT FOR USE WITH ADVANCE A1/ADVANCE CR/ADVANCE BF GAUGE METER DF07703

Defi-Link ADVANCE SYSTEM is the next generation system that adopted the interactive communication. Defi-Link ADVANCE Control Unit is necessary to operate ADVANCE A1, ADVANCE CR, ADVANCE BF, and ADVANCE ZD.

MAIN SPECIFICATIONS, FUNCTIONS, AND FEATURES

• ADVANCE System
• Necessary for ADVANCE gauges and displays
• Switch unit attached
• Driving data can be recorded & replayed
• Illumination ON/OFF: interlocked with vehicle illumination switch
• Illumination color: White (switch)
• Indicator output

FEATURES

• Interactive communication advanced system is implemented.
• ADVANCE Control Unit can control up to 7 Defi-Link Meter ADVANCE CRs and ADVANCE BFs all in at a time. (Ex. 4 ADVANCE CRs and 3 ADVANCE BFs)
• Gauges can be controlled from distance with the included switch unit.

• Opening and closing modes can be selected from 2 variations.
• The installation of additional gauges is easy. Just connect it with the other two gauges and attach the wire to Advance Control Unit.
• Power source indicator (blue LED) assures correct wiring.

• Warning by buzzer sound when the warning LED is on (buzzer sound can be turned on / off).
• Peak value and warning value during driving are stored. Driving data can be stored and replayed up to 3 minutes.
• With both fuel pressure gauge and turbo installed, differential pressure can be monitored on the fuel pressure gauge screen.
• ADVANCE Control Unit is threadably mountable.
