HKS Hipermax R Coilover Suspension Kit – Honda Civic Type R FK8

Brand: HKS
Product: Coilover Suspension Full Kit Hipermax R – Civic Type-R FK8
Part Num: 80310-AH003

SPECIFICATIONS:
Series: Hipermax R
Spring Rate N/mm (kgf/mm):
– Front: 118(12)
– Rear: 98(10)
Free Height (mm):
– Front: 150 (Barrel)
– Rear: 150 (Barrel)
Recommended Range to change Spring Rate N/mm (kgf/mm):
– Front: N/A
– Rear: N/A
Damper Force (Rebound/Damping):
– Front: 1172/530
– Rear: 294/280
– Note: Damping force is at piston speed 0.1m/sec.
Default position of Dial:
– Front: 15
– Rear: 15
Damping Force Adjustment:
– Front: 30 Steps
– Rear: 30 Steps
Height Adjustable Lower Bracket:
– Front: Yes
– Rear: Yes
Upper Mount:
– Front: Pillow Ball
– Rear: Pillow Ball
Damper Layout:
– Front: Inverted
– Rear: Normal
Damper/Spring Layout:
– Front: Coilover
– Rear: Separate
Damping force adjustable with Wire:
– Front: N/A
– Rear: Yes
Helper Spring (Spring Rate N/mm):
– Front: 19.8
– Rear: 19.8
Ride Height Specification –
-Default Ride Height Change (mm):
— Front: -23
— Rear: -28
-Ride Height Adjustability Range (mm):
— Front: -11 – -39
— Rear: -3 – -52
