SKU: 80310-AN003HKS Hipermax R Coilover Suspension Kit – R33 R34 GTR BCNR33 BNR34
Available from supplieriOrdered in from our supplier – we will confirm the estimated arrival after you order.
$3,450.00
Available on back-order
Delivery & pickup
Click & collect from our Ingleburn (NSW) workshop is available at checkout.
Secure payment options
afterpayPay by card or PayPal, or split it into 4 interest-free payments with Afterpay.
Why buy from ASI?
- Genuine JDM parts direct from Japan
- Our own warehouse in Japan
- Fast dispatch & click & collect in Ingleburn
- ★ 5.0 on Google (37 reviews)
Can’t find the part you need?
We specialise in sourcing rare and discontinued JDM parts. Send us the part number or your vehicle details and we will track it down.
Description
Brand
HKS
Compatibility
R34 GTR BNR34
R33 GTR BCNR33
OEM Part Number
80310-AN003
Specification
| FRONT | ||
|---|---|---|
| Damping force adjustment | 30 steps | 30 steps |
| Base valve | – | – |
| Height adjustable lower bracket | 〇 | 〇 |
| Upper mount | Spherical bearing | Spherical bearing |
| Inverted/Normal type | Normal | Normal |
| Damper/Spring layout | Coilover | Coilover |
| Spring rate change at factory | Possible | Possible |
| Damping force adjustment with wire | – | 〇 |
| Helper spring (Spring rate N/mm) | 〇 (19.8) | 〇 (19.8) |
| F | R | |
|---|---|---|
| Spring rate N/mm(kgf/mm) | 137 ( 14.0 ) | 118 ( 12.0 ) |
| Free height (mm) | 170 | 200 |
| Spring type | Straight | Straight |
| Recommended range to change spring rate N/mm(kgf/mm) | ±20 ( 2 ) | ±20 ( 2 ) |
| F | R | |
|---|---|---|
| Damping force (Rebound/Damping)N* | 1162 / 701 | 647 / 505 |
| Default position of dial | 15 | 15 |
| Remaining damper stroke (Rebound/Damping)mm | 47 / 40 | 60 / 76 |
Additional information
| Weight | 20 kg |
|---|---|
| Dimensions | 100 × 50 × 25 cm |
Reviews (0)
Fit for the Following Vehicles
| Make | Model | Year |
|---|---|---|
| Make | Model | Year |
| Nissan | R33 Skyline / GTR | 95 - 98 |
| Nissan | R34 Skyline / GTR | 99 - 02 |
